Behringer EP4000 Overview
The Europower EP4000 from Behringer is a professional-quality rack mount stereo power amplifier designed for installed applications. The rugged all-steel chassis houses a high-current toroidal transformer and Toshiba/Fairchild power transistors for rock-solid reliability and an ultra-high transient response.
The rear panel of the unit has both XLR and 1/4" inputs, and Speakon and Binding Post outputs, allowing you to connect to virtually any sound system. The system has rear-to-front ventilation to keep the components cool. Protection circuitry protects the unit against overheating and DC overload.
The amplifier also has independent limiters to prevent distortion, front-panel gain controls for each channel, selectable LF filters to reduce hum, and LED lights for monitoring power, signal, and clip status.
Professional-quality rackmount stereo power amplifier for installed applications
All-steel chassis for a long lifespan
High-current toroidal transformer and Toshiba/Fairchild power transistors provide terrific reliability and high transient response
XLR and 1/4" input connectors
Speakon and touch-proof Binding Post outputs
Rear-to-Front ventilation system with air filter for cool, reliable operation
Built-in protection circuitry guards against overheating and DC overload
Power, Signal, and Clip LEDs for easy monitoring
Front-panel gain control knobs
Independent limiters on each channel to prevent overload and distortion
Selectable LF filters remove hum and other distracting low-frequency sounds
Behringer EP4000 Specs
Power Amplifier
| Number of Channels | 2 |
| Power Rating | 8 Ohms:
750 W per Channel
2800 W Bridged
4 Ohms:
1400 W per Channel
4000 W Bridged
2 Ohms:
2000 W per Channel |
Performance
| Frequency Response | 20 Hz to 20 kHz +0/-1 dB (at Rated Power -10 dB) |
| Damping Factor | >300 at 8 Ohms |
| Input Sensitivity | 1.23 V / 4 dBu (at 8 Ohms) |
| Input Impedance | 10 Kilohms (Unbalanced)
20 Kilohms (Balanced) |
| Max Gain | 34 dB |
| SNR | -100 dB |
| THD | <0.02% |
Connectivity
| I/O | 2 x XLR Input
2 x 1/4" Input
2 x speakON Output
2 x Binding Post Pair Output |
Power
| AC Input Power | 100 to 120 VAC, 50 / 60 Hz |
| Current Consumption | 15 A |
| Power Consumption | 2600 W |
Physical
| Display & Indicators | 1 x LED (Power)
2 x LED (Clip)
2 x LED (Signal) |
| Cooling | Fan (Variable Speed) |
| Dimensions | 3.5 x 19.0 x 15.8" / 88.0 x 483.0 x 402.0 mm |
| Weight | 36.6 lb / 16.6 kg |
Packaging Info
| Package Weight | 47 lb |
| Box Dimensions (LxWxH) | 23.5 x 22 x 7" |
UPC: 689076150514
